MIL-C-80036 Cutting Machines, Oxygen Flame And Plasma Arc, Automatic, Stationary, Photoelectric Tracer ControlledThis specification covers stationary, automatic, flame and plasma arc cutting machines for cutting various shapes from steel plate or other materials. The machines are controlled by a photoelectric tracer capable of tracing line drawings. The plasma arc system used with the cutting machines is covered by MIL-C-80090.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16

MIL-C-80036C

TABLE I.

S i z e s and capacities.

3 . 6 Performance. The machine and all components shall function proper-

l y to meet the requirements specified herein. A c c u r a c y of torch travel with

r e s p e c t to the template pattern shall be + 1/64 inch.

The machine shall be

c a p a b l e of negotiating 90 degree turns with not more than a 1/8 inch radius

M a c h i n e s equipped with 4 oxygen cutting torches,

at speeds up to 40 IPM.

s h a l l be capable of cutting SAE 1020 or other low carbon steel 8 inches

t h i c k at a rate of not less than 3 IPM; 6 inches thick at a rate of not less

than 5 IPM; and 1/4 inch thick at a rate of not less than 28 IPM.

Straight

l i n e and contour cutting speed ranges for type I and type II machines shall

b e as specified (see 1.2).

3 . 6 . 1 Additional performance requirements.

P e r f o r m a n c e features re-

q u i r e d i n a d d i t i o n t o , o r i n l i e u o f , t h e requirements herein shall be as

s p e c i f i e d and fully described (see 6.2.1).

3 . 7 Standard equipment.

U n l e s s otherwise specified (see 6.2.1), the

machine shall b e furnished with all standard equipment normally furnished by

t h e manufacturer.

3 . 8 Optional equipment. Optional equipment shall be furnished as spec-

i f i e d and shall b e fully described (see 6.2.1).

3.9

R e p a i r parts.

S u c h repair parts as are specified (see 6.2.1),

s h a l l be furnished.

3 . 1 0 Marking of instruction plates, indicating plates, and nameplates.

A l l words on instruction plates, i n d i c a t i n plates, and nameplates shall be

i n the English language. Characters shall be engraved, etched, embossed, or

stamped in boldface on a contrasting background,

3 . 1 0 . 1 Lubrication chart or plate. Unless otherwise specified (see 6.2.

1 ) , a l u b r i c a t i o n c h a r t o r p l a t e s h a l l be permanently and securely attached

to each machine.

I f a c h a r t i s f u r n i s h e d , i t shall be placed in a trans-
